The JDSU JD745A CellAdvisor Base Station Analyzer is the most optimal test tool for installation and maintenance of cell sites. It contains all the features and capabilities required to perform field testing of cell sites of all wireless technologies, from 2G to 4G. The JD745A are equipped with one?button standard based measurements for wireless signals and offers the full scope of BTS conformance test. Its combined functionality includes spectrum analysis, cable and antenna analysis, power meter, interference analysis, channel scanner, E1/T1 analysis, and signal analysis.

Standard features include:
• Spectrum analyzer
• Cable and antenna analyzer
• RF power meter

Advanced features include:
• Interference analysis
• Channel scanner
• 2-port transmission
• CW signal generator
• E1 and/or T1 analysis
• GPS receiver
• Built-in bias tee
• Optical power meter
• Signal analysis of cdmaOne/cdma2000, EV-DO, GSM/GPRS/EDGE, WCDMA/HSPA+, TD-SCDMA, Mobile WiMAX, LTE/LTE-Advanced— FDD and LTE/LTE-Advanced—TDD

Highlights and capabilities include:
• Full LTE test capabilities
• LTE MBMS (multimedia broadcast multicast service)
• Passive intermodulation (PIM) detection
• Dual spectrum
• Spectrum replay
• Dual spectrogram
• Remote control
• Coverage mapping
• Remote wireless connectivity via Bluetooth

Features

Easy User Interface
The analyzer provides a consistent, intuitive interface throughout its various functions, giving users a common, easy-to-use menu structure.
The analyzer’s built-in help system guides users through each measurement task. They can save a screenshot of any function as a graphic file for report generation and save traces for post-analysis to the instrument’s internal memory or to an external USB memory device. Stored data can be easily transferred to a PC using the USB or Ethernet port.
Users can edit file names using the instrument’s rotary knob that also conveniently functions as an enter button when selecting alphanumeric characters.

Designed for Field Use
The compact, lightweight analyzer is especially convenient for users who perform field measurements.
Its bright, multimode, 8-inch color display enables clear visibility indoors and outdoors.
The operating temperature ranges from –10 to 55°C; and, its rugged bumper protects the instrument to external impacts exceeding the MIL-PRF-28800F class 2 specification.

Automatic Measurements
The analyzer’s Auto Measure function affords complete signal profiling covering RF characterization and modulation quality parameters for up to 10 different carriers.
Auto Measure can be easily executed so the instrument automatically configures and tests every aspect for all carriers regardless of their frequency or modulation type. The analyzer’s configurable channel scanner can track on one measurement screen the power levels for each of 20 carriers operating at different frequencies or modulation types.

Multi Language User Interface
A graphical user interface adapts to different languages for localization worldwide.

Applications:

• Capable of demodulation of all wireless technologies up to LTE
• Easy Auto-Measure function presenting the RF/ Modulation in a summary screen
• Fiber Inspection
• Interference Analysis and PIM detection over CPRI
• Fronthaul and RRH verification over CPRI
